| General |
Parameter |
Unit |
| Drive Type | 6 x 4 | |
| Kerb Weight | 35000 | kg |
| Rated Load | 70000 | kg |
| Total Weight | 105000 | kg |
| Overall Dimension (L x W x H) | 9060 x 3675 x 4230 | mm |
| Max. Travel Speed | 36 | km/h |
| Min. Ground Clearance | 370 | mm |
| Min. Turning Radius | ≤ 13 | m |
| Max. Gradeability | 32 | % |
| Wheelbase | 3850 + 1750 | mm |
| Cabin | Single side narrow-body mining cab | |
| Engine Model/Displacement | Cummins Z14-C540-30 / 14L | |
| Rated Power/Speed | 397/2100 | kw/rpm |
| Max. Torque/Speed | 2400/1100~1500 | N.m/rpm |
| Emission Standard | Euro. III | |
| Gear Box | 8DS260, Gear Ratio: 1 Gear 6.73, 8 Gear 0.75 | |
| Front Axle Load | 25T | T |
| Rear Axle Load | 40T x 2, Ratio: 18.722 | |
| Front Suspension | Double skateboard type with thrust rod structure | |
| Rear Suspension | 8-thrust rod balance suspension, maintenance-free balance shaft | |
| Steering System | Full hydraulic | |
| Frames | Two layer riveted, 1150 Width, 424*118* (12+10), 600L Materials | |
| Braking System | I-Brake, Parking Brake, Dual-Circuit Braking | |
| onFuel Tank Capacitye | 600 | L |
| Tyres | 16.00R25 | |
| Cargo Inner Body Dimension | 6000 x 3400 x 1900 (38.76 m³) | mm |
| Thickness of The Carriage | Bottom 16, Side 12 (NM400 + T700) | mm |
| Lifting system | Multi-section front lifting type | |
